Led Blinking

Project No.01.  LED Blinking it’s turn on and off

It is the simple basic project created using Arduino. LED (Light Emitting Diode) is an electronic device, which emits light when the current passes through its terminals. LED's are used in various applications. It is also used as an ON/OFF indicator in different electronic devices.

In this project, we will connect the LED to the digital pin on the Arduino board. The LED will work as a simple light that can be turned ON and OFF for a specified duration.

Hardware Required : Arduino Board, LED, Resistor 220Ω







CODE



void setup()

{

  pinMode(13, OUTPUT);     // pin# 13 is output

}

void loop()

{

  digitalWrite(13, HIGH);   // turn the LED ON

  delay(1000);              // wait for a second

  digitalWrite(13, LOW);    // turn the LED OFF

  delay(1000);              // wait for a second

}



Description of the code











 ..................................................................
